Technical Specs

• PowerPC 604e CPU card
• A.S.P.D. - Allows upgrade of primary processor with a 604e-family CPU card, or addition of a second processor using a P-series processor card
• Built-in floating-point processor and 64K on-chip cache
• High-speed system bus (up to 50 MHz)

• DayStar nPOWER Technology
  Asymmetric multiprocessing under the Mac OS for a performance increase of up to 80% over a single processor of the same speed.
• Multiprocessing Software
  More of your favorite software will benefit from multiprocessing:

  • Adobe Photoshop
  • Adobe Premiere
  • Apple QuickDraw 3D
  • Adobe After Effects
  • Cinepak
  • Strata StudioPro Blitz
  • BeInfinite Infinite FX/1
  • Emerson Kennedy PowerTap
  • MetroWerks CodeWarrior
  • Apple QuickTime
  • Deneba Canvas
  • Kodak Color Processor
  • Leaf Catch Light Digital Camera
  • TrueVision M-JPEG Codec (TARGA 2000)
  • Many more....

• 16 MB of interleaved memory RAM on motherboard, expandable to 1 Gigabyte
• 64 MB of RAM for S900DP/250, S900i/250, and S900BASE models (via two 16 MB and two 8 MB DIMMS in addition to on-board RAM)
• 8 DIMM slots
• DIMM memory modules should be non-composite, 168-pin, 5 volt, 64-bit wide with 70ns access time or faster. Compatible with EDO or FastPaged DRAM. See the Memory Technical Report for more info.
• 128-bit wide data path from DRAM to processor
• 4MB of 64-bit wide burst ROM
• 512K Level 2 Cache

• Internal 100 MB Iomega Zip drive (S900/250 only).
• Internal 2GB Fast SCSI-II hard drive (4GB Ultra SCSI in S900i, 4GB Ultra SCSI RAID in S900DP)
• Internal 3.5" SWIM III 800/1.44 MB floppy disk drive that reads, writes, and formats Macintosh, Windows, DOS, OS/2, and ProDOS disks
• Internal CD-ROM drive (see table above for specifics)

• 53C94-compatible Fast SCSI-II interface
• Internal SCSI bus (Bus 0) (up to 10 MB/sec)
• External SCSI bus (Bus 1) (up to 5 MB/sec)
• Upgradable to Ultra-Wide SCSI-III with the E100 Extended Performance Card

• 6 PCI Slots for PCI cards with standard brackets. All PCI cards should not exceed a total of 90 watts.
• DEC 21052 PCI-to-PCI Bridge chip provides direct PCI-PCI card data transfers
• 1 enhanced PCI slot for the E100 Extended Performance Card
• 3 internal 3.5" drive bays available (two front accessible)
• 1 internal front accessible 5.25" drive bay available
• 2 serial ports
• 2 ADB ports

• IX Micro Twin Turbo Graphics Accelerator card installed
• Resolutions up to 1920x1080 pixels
• 24-bit color up to 1152x870-pixels resolution
• 24-bit color up to 1920x1080-pixels resolution with 8MB VRAM

• 16-bit CD-quality stereo sound
• 44.1K bandwidith
• Analog CD audio recording/playthrough
• Bottom front bezel-mounted stereo audio in/out jacks. Supports Apple PlainTalk microphone
• An additional rear-mounted stereo audio out jack
• Input line level - 2 volts peak-to-peak nominal, into 6.5k ohm impedance
• Output line level - 2.2 volts peak-to-peak nominal, into 1k ohm impedance
• Input through output signal to noise ratio (SNR) = > 86 decibels (dB) with no audible discrete tones
• Total harmonic distortion plus noise (THD+N) = Less than 0.06%; measured 30Hz-16kHz with a 2 Vpp, sine wave input

• On-board Ethernet (10Base-T and AAUI connections)
• Upgradable to 100Base-T with the E100 Extended Performance Card (standard on 250MHz machines)
• Two high-speed RS-232/RS-422 serial ports compatible with LocalTalk and GeoPort

• Long-life lithium battery to power clock/calendar/parameter RAM

• ATX standard mini-tower enclosure, which allows for easy expandability
• Front bezel-mounted reset switch and programmer's NMI switch
• Front bezel-mounted power on LED indicator
• Front bezel-mounted monaural speaker
• Thermal design enhances airflow through chassis from front to back

• ADB extended keyboard included
• ADB mouse included

• Height: 17.25 inches (43.8 cm)
• Width: 7.0 inches (17.8 cm)
• Depth: 17.5 inches (44.5 cm)
• Weight: 28 pounds (12.7 kg)

• Line voltage: 100-105 or 200-240 VAC (user selected)
• Frequency: 50/60 Hz, 8/4 amps single phase

• PC-Standard 250W soft/trickle power supply, which allows computer to be turned on or off through software or the keyboard's power-on key

• Operating temperature: 50 to 104 degrees F (10 to 40 degrees C)
• Storage temperature: -40 to 116 degrees F (-40 to 47 degrees C)
• Relative humidity: 5 to 95%, non condensing
• Maximum altitude: 10,000 feet (3,048m)

• Apple Mac OS
• Asanté NetDoubler
• FWB CD-ROM Tool Kit
• FWB HD ToolKit
• MicroMat TechTool Pro Diagnostic
